Minelab EQUINOX 900 Metal Detector
The Minelab EQUINOX 900 is an advanced all-terrain detector built for coins, relics, jewelry, beach hunting, and gold prospecting. Powered by Minelab Multi-IQ technology, the EQUINOX 900 combines multiple frequencies at the same time for strong performance across parks, fields, beaches, goldfields, and underwater conditions.
What’s Included
The Multi-IQ Advantage
With Minelab Multi-IQ technology, the EQUINOX 900 gives you the combined power of multiple detectors working at the same time. It is built to find coins, gold, jewelry, and relics across a wide range of soils and terrains.
No terrain is off limits: park, field, beach, and goldfield detecting are all built into one detector platform.
Waterproof to 16 Feet
The EQUINOX 900 is IP68 waterproof to 5 meters / 16 feet, making it ready for wet sand, surf, shallow water, creeks, rain, mud, and demanding detecting conditions.
Whether you are searching on dry land or in the water, the EQUINOX 900 is built for serious all-terrain detecting.
Target Separation and Precision
Recovery Speed and Iron Bias controls help manage multiple signals in trashy ground. The EQUINOX 900 can separate good targets from iron and help identify coins, jewelry, relics, and gold hiding among junk targets.
The 119-segment high-resolution Target ID scale gives more detailed target information than earlier EQUINOX models. When you have a target, Pinpoint Mode helps zero in for cleaner recovery.
Key Features
Multi-IQ Technology
Simultaneous multi-frequency performance for coins, relics, jewelry, beach hunting, and gold.
4 Search Modes
Park, Field, Beach, and Gold modes with two custom profiles per mode.
6 Single Frequencies
Choose from 4, 5, 10, 15, 20, and 40 kHz when a specific single frequency is preferred.
IP68 Waterproof
Fully waterproof to 5 meters / 16 feet for all-terrain and shallow water hunting.
High Resolution Target ID
119 Target ID segments give more detailed target identification.
Advanced Audio Control
Multiple tone audio options help identify target size, depth, and target type by sound.
Light and Compact
3-piece carbon-fiber shaft weighs only about 2.8 lbs and collapses to about 24 inches.
Lighting and Vibration
Control pod flashlight, red backlight display, backlit keypad, and handgrip vibration.
Wireless Audio Included
Includes Minelab ML85 Low Latency wireless headphones for clear wireless audio.
EQUINOX 900 Features
Advanced Audio Control
Multiple tone audio options help you hear target size, depth, and target type more clearly.
Lighting and Vibration
Flashlight, red backlight display, backlit keypad, and handgrip vibration help extend your hunt.
Loud and Clear Audio
Use the included ML85 wireless headphones, built-in speaker, wired headphones, or waterproof headphones.
Extreme Precision
Stable IDs and Pinpoint Mode help you decide when to dig and zero in on targets accurately.
Supreme All-Terrain Detecting
Whether you are swinging in goldfields, parks, fields, or at the beach, EQUINOX 900 is built for all targets and all terrains.
General Features
- Multi-IQ simultaneous multi-frequency technology
- Single frequencies: 4, 5, 10, 15, 20, and 40 kHz
- Search modes: Park, Field, Beach, and Gold
- 8 custom search profiles
- User Profile button
- 119-segment high-resolution Target ID
- Auto and manual Noise Cancel
- Auto, manual, and tracking Ground Balance
- Recovery Speed adjustment from 1 to 8
- Iron Bias adjustment from 0 to 9
- Pinpoint Mode
- Wireless audio compatibility
- Red display and keypad backlight
- Control pod flashlight
- Handgrip vibration
Why Choose the EQUINOX 900?
The EQUINOX 900 is a strong choice for detectorists who want a fully loaded all-terrain machine with advanced target separation, high-resolution Target ID, superior audio controls, waterproof construction, and two included coils.
The EQX11 coil gives strong coverage and depth, while the EQX06 coil is excellent for tight spaces, trashy locations, and target separation.
Minelab EQUINOX 900 Tech Specs
| Product | Minelab EQUINOX 900 Metal Detector |
|---|---|
| Search Modes | Park, Field, Beach, Gold |
| All-Metal Shortcut | Yes |
| Custom Search Profiles | 8 |
| User Profile Button | Yes |
| Operating Frequencies | Multi, 4, 5, 10, 15, 20, 40 kHz |
| Noise Cancel | Auto, 19 Channels / Manual |
| Ground Balance | Auto, Manual, Tracking |
| Sensitivity | 1 to 28 |
| Target Volume | 0 to 25 |
| Threshold Level | 0 to 25 |
| Threshold Pitch | 0 to 25 |
| Target Identification | 119-segment notch discrimination: Ferrous -19 to 0 / Non-ferrous 1 to 99 |
| Target Tones | 1, 2, 5, All Tones, Depth |
| Tone Break | Ferrous, Non-ferrous: T1, T2, T3, T4 |
| Tone Pitch | All tones adjustable, 0 to 25 |
| Tone Volume | All tones adjustable, 0 to 25 |
| Recovery Speed | 1 to 8 |
| Iron Bias | 0 to 9 |
| Depth Indicator | 5 levels |
| Discrimination Segments | 119 segments |
| Pinpoint Mode | Yes |
| Wireless Audio | Yes |
| Length | Collapsed: 61 cm / 24 in | Extended: 144 cm / 56.7 in |
| Weight | 1.27 kg / 2.8 lbs |
| Display | Monochrome LCD |
| Display and Keypad Backlight | Red backlight: Off, High, Medium, Low |
| Flashlight | On / Off |
| Vibration | On / Off per Tone Region |
| Supplied Coils | EQX11 11" Double-D coil with skid plate and EQX06 6" Double-D coil with skid plate |
| Audio Output | Built-in loudspeaker, wired 3.5 mm headphones, wireless headphones |
| Supplied Headphones | Minelab ML85 Low Latency wireless headphones |
| Battery | 3.7V / 5100mAh internal lithium-ion battery |
| Included Accessories | Getting Started Guide, Screen Protector, Charging Cable, EQX11 coil, EQX06 coil, ML85 headphones |
| Waterproof | IP68 waterproof to 5 m / 16 ft |
| Operating Temperature | -10°C to +40°C / +14°F to +104°F |
| Storage Temperature | -20°C to +70°C / -40°F to +158°F |
| Key Technologies | Multi-IQ |
| Warranty | 3 years, control box and coil |
